PD795Ex

Handheld ATEX | DMR

Highlights

diagram indicating highlights of PD795Ex

Innovative Construction

Both the radio and the battery are encapsulated to ensure that all internal connections are protected and sealed off from dangerous explosive gases and dust particles. The high-strength LCD is scratch and impact resistant

Fail-safe Design

Batteries or accessories with a lower level of protection automatically trigger an alarm, whilst a patented latch ensures the battery remains securely attached even when knocked or dropped

GPS Location

Positioning and tracking as standard, also including man down feature

Rugged and Reliable

Dust and waterproof, rated IP67, sustaining performance in harsh environments

Clear Communication

Thanks to the latest audio processing technology and in-built speaker, the PD795Ex offers you outstanding audio quality and noise cancellation

Functions

Created with Sketch. Priority Interrupt

Send a priority transmission to interrupt other calls, ideal for important, critical messages.

Created with Sketch. Pseudo Trunking

Using pseudo-trunking, a Hytera patented technology, slots can be shared to improve capacity usage with transmissions either direct to handset or to repeater.

Created with Sketch. Intelligent Audio

Combining noise cancelling technology to remove nusiance noise from the transmission, with powerful speakers to deliver clear communications.

Created with Sketch. GPS

Enabling location based services to improve safety and control.

Hytera Pd795 Ex 73

Created with Sketch. Roaming

This feature allows the radio to switch between sites on Multi-site Conventional and XPT systems, ensuring seamless communication.

Created with Sketch. Emergency Mode

Raise an alarm with top priority to a base station or to other radios with the pre-programmed emergency mode, identifying the ID of the person issuing the alarm. Also receive emergency notifications.

Created with Sketch. Lone Worker

The lone worker feature uses a timer in the radio to measure inactivity. If the timer expires, a warning is issued, and if there is no response to that, the alarm is triggered.

Created with Sketch. Man Down

The man down feature will let you know if the radio has been tilted past a certain angle. This may happen for instance if the radio user has fallen over or is unconscious or injured. The alarm will be triggered after a warning is issued to the user.

Accessories for PD795Ex

Included as standard with PD795Ex Included as standard with PD795Ex

Antenna

Charger & Power

Mounting

Carrying

Audio

Cables

Battery

Related products that work with the PD795Ex

Technical Specifications

General

Frequency Range
VHF: 136-174MHz UHF1: 400-470MHz
Channel Capacity
1024 (64 zones with 256 channels per zone)
Digital Protocol
ETSI-TS102 361-1,2 & 3
Battery
1800mAh
Battery Life
Analogue 14.5h, Digital 17h
Dimensions(W×H×D)
141 X 55 X 39(mm)
Weight
495g (with standard battery)
Display
160 x 128 pixels, 65536 colours 1.8 inch, 4 rows
Keypad
Full keypad
Programmable Buttons
5

Environmental Specifications

Dust & Water Intrusion
IP54 Standard

Features

RRS
YES
Telemetry
YES
Option Board
NO
Intrinsically Safe Option
YES
Bluetooth Audio
NO
Radio Check
YES
Alert Call
YES
Stun / Unstun
YES
Remote Monitor
YES
IP Site Connect
YES
Work Order
YES
5 Tone Signalling
YES
2 Tone Signalling
YES
HDC1200 Signalling
YES
DTMF (Phone Patch)
YES
VOX
YES
Priority Scan
YES
GPS SMS
YES
Vibration
NO
Emergency Mode
YES
Lone Worker
YES
Mandown
YES
Scrambler (Analogue)
YES
Digital Encryption
Basic encryption as standard (10, 32 & 64 character keys). 40 bit Enhanced Encryption as Standard (latest firmware required)Advanced encryption (Hytera or DMRA 128 bits and 256bits AES) available via chargeable licence file.
Multiple Key Encryption Decode
YES
Multilanguage Menu
YES
Power on & off user logo programming
YES
Voice Interrupt
Yes (TX Interrupt for voice call, emergency call, remote dekey, text message.)
No of Contacts (Conventional)
Digital 1024 Analogue 2-Tone 32 Analogue HDC1200 200 Analogue 5-Tone 255
No of Contacts (Trunking)
Private Contacts 512 Group Contacts 1024
Text Messaging
256 characters
Quick Text Messages
Up to 25 pre-programmed via CPS
MPT1327 / 1343 Trunking
Yes via free of charge licence key
Tier 3 Trunking
Available via chargeable licence file
Over-the-Air Programming
Yes via smartdispatch 4.0
Analogue Only Version
Not Available
Data Services via Bluetooth
N/A
Auto Power Select
Yes (V8.0 firmware or later)
