HP78X
The HP78X represents the future on style and functions that refreshes the standards in digital radios, providing more efficient and more reliable communication with loud and clear audio, powerful battery, remarkable portability and ruggedness for ease of use across multiple environments and industries.
Highlights
Functions
Accessories for HP78X
Included as standard with HP78X
Antenna
Charger & Power
Mounting
Audio
Cables
Battery
Carrying
Related products that work with the HP78X
Technical Specifications
General
- Frequency Range
- UHF: 350-470 MHz VHF: 136-174 MHz
- Channel Capacity
- 1024
- Zone Capacity
- 64
- Dimensions(W×H×D)
- 132 x 55 x 29.5mm
- Weight
- 310g
- Display
- 2.4 inch LCD
- Keypad
- Full Keypad
- Battery Life (5-5-90 Duty Cycle)
- 24h (GNSS disabled) 20h (GNSS enabled)
Receiver
- Sensitivity
- Analogue: 0.18µV (12dB SINAD)
- Analogue: 0.16µV (12dB SINAD) (typical)
- Digital: 0.18µV / BER 5%
- Selectivity
- TIA-603: 60dB @12.5kHz / 70dB @20/25kHz
- ETSI: 60 dB @12.5kHz / 70dB @20/25kHz
- Intermodulation
- TIA-603: 70 dB
- ETSI: 65 dB
- Spurious response rejection
- TIA-603: 70 dB
- ETSI: 70 dB
- Blocking
- TIA-603: 80 dB
- ETSI: 84 dB
- Hum and noise
- 40 dB @12.5kHz
- 43 dB @20kHz
- 45 dB @25kHz
- Related audio power output
- 0.5 W
- Rated audio distortion
- <3%
- Audio response
- +1 to -3 dB
- Conducted spurious emission
- < -57 dBm
Transmitter
- RF power output
- UHF: 1W / 4W
- VHF: 1W / 5W
- FM modulation
- 11K0F3E @12.5kHz
- 14K0F3E @20kHz
- 16K0F3E @25kHz
- 4FSK digital modulation
- 12.5kHz data only: 7K60FXD
- 12.5kHz data and voice: 7K60FXW
- Conducted/radiated emission
- -36dBm @<1GHz; -30dBm @>1GHz
- Modulation limiting
- ±2.5kHz @12.5kHz; ±4.0kHz @20kHz; ±5.0kHz @25kHz
- FM hum and noise
- 40dB @12.5kHz; 43dB @20kHz; 45dB @25kHz
- Adjacent channel power
- 60dB @12.5kHz; 70dB @20/25kHz
- Audio response
- +1 to -3 dB
- Audio distortion
- <3%
- Digital vocoder type
- AMBE+2™
- Digital protocol
- ETSI-TS102 361-1,-2,-3,-4
Environmental Specifications
- Dust & Water Intrusion
- IP68
- Humidity
- MIL-STD-810G
- Shock and Vibration
- MIL-STD-810G
Location Service
- GNSS
- GPS, GPS+GLONASS, GPS+BDS
- TTFF (time to first fix) cold start
- < 1 minute
- TTFF (time to first fix) hot start
- < 10 seconds
- Horizontal accuracy
- < 5 meters
