Ku-Band Drive-Away
DRIVE-AWAY TERMINAL
The new WAYFARER drive-away is Norsat’s solution for reliable and easy-to-deploy mobile communications. The solid, low-weight, and low-height reflector mount deploys easily for fast and reliable satellite acquisition and tracking. Whether mounted on an emergency vehicular command center or a mobile broadcast van – count on Norsat’s WAYFARER drive-away terminals for mobile broadband-level communications capability. This terminal is ideal for mobile offices, satellite news gathering, broadcasting, governments, first responders, and emergency mobile headquarters.
Highlights
Functions
Easy and intuitive web-based LinkControl™ Interface
Heavy duty platform and reflector folding design
Lightweight and durable carbon fiber reflector
Fast, simple, intuituve one-button deployment on ACU
From “stow-to-go” in under 5 minutes
Automatic 3-axis acquisition
Wide range of Norsat BUC and LNB configurations
Includes easy-to-use IRU ACU for easy indoor operation
Accessories for Ku-Band Drive-Away
Included as standard with Ku-Band Drive-Away
Related products that work with the Ku-Band Drive-Away
Technical Specifications
ELECTRICAL
- Reflector aperture
- 1.2m
- Reflector material
- Carbon fiber
- Reflector type
- Offset
- Tx frequency
- 13.75 to 14.5 GHz
- Rx frequency
- 10.70 to 12.75 GHz
- Tx gain
- 42.8+20log(f/14.25) dBi
- Rx gain
- 41.5+20log(f/12.5)dBi
- Polarization
- Linear
- Cross polarization
- ≥35 dB (Axial)
- Rx/Tx isolation
- Rx ≥ 40dB Tx ≥ 85 dB
- Sidelobe
- First sidelobe ≤ -14 dB
- Azimuth range
- ± 200°
- Elevation range
- 10° to 90°
- Polarization range
- ± 90°
- Azimuth speed
- 0.1°/s to 6°/s
- Elevation speed
- 0.1°/s to 6°/s
- Polarization speed
- 0.1°/s to 6°/s
- Feed interface
- WR75
- Power supply
- AC110-230V 50/60Hz, rated 200W, 500W max
MOUNTING
- Weight
- ≤85 Kg
- Stowed size
- 176 cm (L) × 121 cm (W) × 42 cm (H)
ENVIRONMENTAL
- Wind load - operational
- 72 km/h
- Wind load - survival
- 90 km/h
- Temperature
- -40°C to +55°C
- Humidity
- 0-95%
- Water ingress
- IP 65
